Automatic Precise CNC Turning And Milling Machine Y Axis 200mm Length

Price : Contact Us

MOQ : 1

Packaging Details : wooden box package

Delivery Time : 45-60 days

Payment Terms : T/T

Supply Ability : 20 units/month

type : TURNING CENTER

max. length of workpiece (mm) : 200

machining capacity : Heavy Duty

max. weight of workpiece(kg) : cnc lathe

width of bed (mm) : 35 mm

no. of spindles : Single

number of axes : 5

travel (x axis)(mm) : 800 mm

travel (z axis)(mm) : 300 mm

positioning accuracy (mm) : ±0.003

repeatability (x/y/z) (mm) : ±0.003

place of origin : Guangdong, China

dimension(l*w*h) : 2200*1750*2000

brand name : LBIE

model number : L2-6ZYDP

voltage : 380v

cnc control system : FANUC\Syntec

tool post stations : 12, 15

weight (kg) : 3000

warranty : 1 Year

key selling points : High cost-effectiveness

machinery test report : please consult

video outgoing-inspection : please consult

range of spindle speed(r.p.m) : 0 - 4000 r.p.m

cutting torque : 59.7 N.m

Lubrication Form : Oil lubrication

Fixture : Hydraulic Chuck

Hydraulic System : 2 Channels

CNC or Not : CNC

Coolant Pump Power : 370W

Tool Carrier Form : 4+4Live Tool Component with cooling machine Gang tool carrier

Rapid Feedrate : 22 m/min

Condition : New

Spindle Bore(mm) : 45

Max. Spindle Speed (r.p.m) : 4500

Warranty of core components : 1 Year
